External Vibrator 6000vpm

Price 25000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

External Vibrator 6000vpm Specification

Motor Power
0.75 HP (Approx)

Surface
Anti-Corrosive Finish

Product Type
External Vibrator

General Use
For Compacting Concrete, Construction Industry

Material
Cast Aluminum Body

Type
Electric Vibrator

Capacity
6000 vpm (Vibrations Per Minute)

Weight (kg)
22 kg

Computerized
No

Automatic
No

Control System
Manual

Cooling System
Air Cooled

Method
Electric Driven

Voltage
230V/415V AC, 50 Hz

Dimension (L*W*H)
Approx 330 x 180 x 220 mm

Feature
High Frequency, Compact Design, Low Maintenance

Color
Yellow & Black

RPM
3600 RPM

Noise Level
Low

Frequency
50/60 Hz

Usage/Application
Concrete Compaction for Precast and Moulds

Operating Temperature
-10°C to +50°C

Packing Type
Carton Box or Wooden Case

Vibration Force
Up to 600 Kgf (Kilogram-force)

Ingress Protection
IP55

Insulation Class
F

Service Life
Long Operational Durability

Phase
Single/Three Phase

Mounting Type
Base Plate Mounted

Cable Length
2.5 Meter

About External Vibrator 6000vpm

Experience sterling performance with the External Vibrator 6000vpm, a featured solution designed for efficient concrete compaction in precast and mould applications. Procure this exceptional unit, with a robust cast aluminum body and a compact, anti-corrosive finish, for sensational operation in the construction industry. Its advanced IP55 ingress protection, low noise level, high vibration force up to 600 Kgf, and dual voltage compatibility make it a reliable choice. Advance purchase ensures timely integration into your workflow, accompanied by long operational durability and low maintenance.

Versatile Application for Concrete Compaction

The External Vibrator 6000vpm is specifically used for compacting concrete in precast and moulds, making it ideal for the construction industry. Suitable for both single and three-phase operations, this manual, electric-driven unit delivers high-frequency vibrations for even compaction. Simply secure the base plate-mounted vibrator onto the desired surface and activate it for effective, uniform results. Its compact design and user-friendly application method streamline construction processes and improve overall productivity.

Reliable Supply & Swift Dispatch Processes

Our supply ability ensures consistent product availability, with drop-off and packing & dispatch scheduled based on your requirements. The External Vibrator 6000vpm is carefully packed in either carton boxes or sturdy wooden cases, guaranteeing safe transit. Payment terms are flexible and detailed estimates are provided upfront for your convenience. We prioritize timely delivery and dependable packing, so your order arrives ready for immediate on-site installation across India or globally.

FAQ's of External Vibrator 6000vpm:

Q: How do I install the External Vibrator 6000vpm for concrete compaction?

A: To install, simply mount the unit using the base plate onto your formwork or mould, secure it properly, and connect to the appropriate power supply based on your phase requirements.

Q: What benefits does the External Vibrator 6000vpm offer for precast concrete applications?

A: The vibrator provides uniform compaction, reduces air voids, and ensures superior surface finish in precast and moulded concrete, enhancing structural integrity.

Q: When is it ideal to use this external vibrator in the construction process?

A: It is ideally used during the pouring and setting stages of concrete to ensure maximum density and minimize potential defects in precast or moulded components.
